UL20242 FEP Insulated Heat Resistant Electric Cable

UL20242 FEP Insulated heat resistant electric cable is widely applied in the industries of home appliance, lighting, electronic product, instrument and apparatus, electric motor and industrial equipment. Our product can be used in home appliance and electronics, inner wires for the former, such as air conditioner, microwave oven, electronic disinfector, electric rice cooker, electric thermos bottle, electric heater, electric oven and electric frying pan, as for the latter, our product functions as temperature compensation wire, cold-resistant wire, heating wire, anti-aging wire and fire-retarded wire.

Parameters
Rated Voltage: 300/500V
Rated Temperature: 200℃~+105℃
Standard: UL758 CSA22.2
Application: used as the connecting wire of lighting, home appliance and elctronics
Color: white, black, red, brown, yellow, blue, green, olivine, lucency

Specification:
Conductor Insulation Packing
Size AWG Cross Sectional Area (mm2 ) Strand Insulation Thickness (mm ) Jacket Thickness (mm ) Diameter (mm) m/coil
20x2c 0.50x2c 19/0.185 ≥0.30 ≥0.58 5.0 ±0.2 (200)
18x2c 0.75x2c 19/0.235 5.2 ±0.2 (200)
17x2c 1.00x2c 19/0.26 5.2 ±0.2 (200)
16x2c 1.25x2c 19/0.30 6.0 ±0.3 (100)
15x2c 1.50x2c 19/0.32 6.0 ±0.3 (100)
14x2c 2.0x2c 19/0.37 6.5 ±0.3 (100)
20x3c 0.50x3c 19/0.185 5.0 ±0.2 (200)
18x3c 0.75x3c 19/0.235 5.2 ±0.2 (200)
17x3c 1.00x3c 19/0.26 5.5 ±0.2 (200)
16x3c 1.25x3c 19/0.30 6.0 ±0.3 (100)
15x3c 1.50x3c 19/0.32 6.5 ±0.3 (100)
14x3c 2.0x3c 19/0.37 7.0 ±0.3 (100)
